SPECIFICATION

Protocol character:

• Open Protocol
• 8 bit data format, Suitable for PC Programing
• Baud rate is optional, O type max to 57600
• Scalability, easy to add more function
• Presseting all kinds of funtions, like gravity compensation and temperature compensation
• Portability, easy to transpalant to other platform such as CAN

Hardware:

• Power : AC switch power 110V-220V/AC | No DC
• LC Interface : Communication | way : RS 485 | Baud rate : 19200bps | Transmite : distance : less than 50m
• Scoreboard interface : Rs 232, current loop : Rated baud rate is 600bps

Character:

• Open Protocol
• Support U type Digital LC
• High Performance 485 communication chip
• LC Interface have surge protection meansures
• Support auto network, Scale group
• Support Scale setting abnormal detecting
• Auto storage 1000 set weighing record, no need cancels record
• Support PC communication interface self-detecting

Basic Function:

• Calibration and parameter setting operated separetaly
• Score board interface
• Serial communication interface
• Standart pararel print interface, customizable print format
• Comprehensive configuration EMC electromagnetic, compatibility protection measures
• Support Scale setting abnormal detecting
• Auto storage 1000 set weighing record, no need cancels record
• Support PC communication interface self-detecting
