SPECIFICATIONS |
|
Accuracy Grade | Class |
A/D converting theory and sampling rate | double integration, 10-15 times/time |
Maximum inner codes | 500000 codes/time |
Non-linearity | 0.01% F.S. |
Stimulating voltage for the loadcell | DC +8V, the maximum input signal is about 16 mV |
Loadcell quantity | 1 load cell, 4 pins, (no long distance compensation) |
Temperature coefficient on F.S | 8 PPM/C |
Display | 6-bit LED, 0.56 inches in height, 6 status indicating lights, 3 battery charges indicating lights |
Keyboard | 5 slight-touch keys/C |
Power supply | 1. AC 187-242 V, 50 HZ 2. Built-in chargable battery 6V, 2.8 AH (2 pcs in serial connection) |
Operating temperature and humidity | 0-40C, 90% RH |
Storage temperature | -20--+50C |
Fuse | 500mA |
External dimension | 265 190 170mm |
weight | 1.53kg (not including the battery) |
