SPECIFICATIONS
|
| Weighing Capacity |
12000g |
| Resolution |
0.1g |
| Repeatability (Std. Deviation) |
0.1g |
| Linerarity |
± 0.2 g |
| Stabilization Time |
1.5s (Type at FAST Mode |
| Sensitivity Drift (50°F - 86°F) |
± 3 ppm / °C |
| Operating Temperature |
5°C to 40°C (41°F to 104°F) 85% relative humidity or less |
| Sensing Method |
Super Hybrid Sensor (SHS) |
| Display Type |
Vacuum Fluorescent Display (VHD) |
| Display Tefresh rates |
5 times/s or 10 times/s |
| Weighing Units and Modes |
g, kg, lb:oz, ct, dwt, ozt, mm, TL, MS, t, DS and percent % and counting PCS |
| Counting Mode |
0.1g |
| Percent Mode |
10g |
| Standard interface |
RS-232C Serial interface with Windows Communication Tools (WinCT) |
| Recomended External Calibrating Weight |
5 - 10 kg |
| Water & Dust proof level |
Compilance with IP-65 covers the entire device |
| Weighing Pan |
Stainless steel weighing pan 15.1" x 13.5" (Wash down type) |
| Calibration |
Motor-Driven internal calibration with SHS (internal mass approximately 300 g) |
| External Dimensions |
14.6" x 24.2" x 5.1" |
| AC Adapter |
100, 120, 220, 240, VAC (AC Adapter) 50/60 hz All balances shipped with 120V AC Adapter. For other volteages add $25.00 |
| Power |
Approximately 11VA (supplied by AC adapter) |
| Net Weight |
Approx. 17kg |
